Garrett 846098-5002S Supercore GTX Series GTX3584RS, Trim 64

Garrett GTX3584RS supercore — a balanced core assembly (centre cartridge with compressor cover and back plate) for building or rebuilding GTX turbochargers.

Garrett by Honeywell, is excited to announce the release of our newest turbocharger, the GTX3584RS.

The GTX3584RS is a clean-sheet product with many new features geared towards enthusiasts.

The new turbine wheel design allows for higher exhaust gas flow which increases aerodynamic efficiency compared to the previous design.

New hi-flowing, stainless steel turbine housings help decrease backpressure and range in size from 0.83, 1.01, and 1.21 A/R.

Specifications

• Frame: GTX35
• Bearing: ceramic ball bearing
• Rotation: standard
• Compressor wheel: 67 mm inducer, 84 mm exducer, 64 trim, 0.72 A/R
• Turbine wheel: 68 mm inducer, 62 mm exducer, 84 trim
• Power: up to 1000 HP
• Displacement: 2.0-5.5 L

Features

• GTX3584RS turbochargers feature a fully-machined compressor inlet, fully-machined compressor outlet, and fully-machined ported shroud
