GARRETT 836026-5016S TURBOCHARGER GT2860R (4 GARRETT 80009-6 HIGH BOOST ACT)

Ball bearing.

Oil & Water cooled bearign system.

Direct replacement upgrade turbocharger for GT2554R (471171-0003) and GT2560R (466541-0001); turbine housing flanges are outline interchangeable.

Uses 480009-0006 actuator.

Great size for applications w/packing constrains.

Ideal for smaller displacement engines making up to 360 Hp.

Turbine housing option available.

Note: The 739548-0010 GT2860R is a customizable Garrett ball bearing GT turbo that is packaged without the turbine housing. (It includes a CHRA and compressor housing.)

• Turbo Part Number | Model | Turbine side | Compressor side
• New Part | Old Part | O.D.mm | I.D.mm | TRIM | A/R | O.D.mm | I.D.mm | TRIM | A/R
• 836026-5016S | 739548-5010S | GT2860R | 53.8 | 47.0 | 76 | w/t | 60.0 | 47.2 | 62 | .60

Applicable Garrett P/N's:

TBO -  739548-0010

CHRA - 446179-0066

C.H.R.A. Part Number

• New Part CHRA | Old Part CHRA
• 835998-5007S | 446179-5066S

Product category: Turbocharger
