KNI18001-1B Clutch Kit Xtreme Performance Heavy Duty Sprung Ceramic 270Nm 485kg (40%)

Xtreme Performance - sprung ceramic kit /-1BRecommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

Specifications:

• Torque capacity 270Nm
• Clamp load 485kg 40% Increased over standard
• Sprung Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

Xtreme PerformanceAt Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

What's in the Box?

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Tech. Info:

Reference: KNI18001-1B

Weight: 4.87

Note:

Clutch Disc Diameter (mm): 180
Clutch Disc Spline Count: 18
Clutch Disc Spline Diameter (mm): 20.5
Torque (Nm): 270
Flywheel Step: 0
Design: Single Plate
Stage: Stage 2
Clamp Load: 485Kg (40% inc.)
Recommended for: Track - Stage 2
Ring Gear Tooth count:
Additional information:

Single Plate

Suitable for:

- Nissan/Almera/N15 | 1.4/1995.09-2000.07/GA14DE 1392 Petrol 64 kW 87 BHP (1995.09 - 2000.07) Until 09/1997,
Nissan/Almera/N15 | 1.4/1995.09-2000.07/GA14DE 1392 Petrol 55 kW 75 BHP (1995.09 - 2000.07) Until 09/1997,
Nissan/Cherry/N10 | 1.3/1981.09-1983.12/E13 1269 Petrol 44 kW 60 BHP (1981.09 - 1983.12)
Nissan/Cherry/N10 | 1.5/1981.08-1982.12/E15 1488 Petrol 51 kW 69 BHP (1981.08 - 1982.12)
Nissan/Cherry/N12 | 1.3/1982.05-1986.10/E13 1269 Petrol 44 kW 60 BHP (1982.05 - 1986.10)
Nissan/Cherry/N12 | 1.5/1983.11-1986.10/E15S 1488 Petrol 55 kW 75 BHP (1983.11 - 1986.10)
Nissan/Cherry/N12 | 1.6/1984.05-1986.07/E16 1597 Petrol 51 kW 69 BHP (1984.05 - 1986.07)
Nissan/Cherry/N12 | 1.7 D/1982.10-1986.12/CD17 1681 Diesel 40 kW 54 BHP (1982.10 - 1986.12)
Nissan/Micra/K11 | 1.0 16V/2000.07-2003.02/CG10DE 998 Petrol 44 kW 60 BHP (2000.07 - 2003.02)
Nissan/Micra/K11 | 1.4 16V/2000.09-2003.02/CGA3DE 1348 Petrol 60 kW 82 BHP (2000.09 - 2003.02)
Nissan/Prairie/M10 | 1.5 S/1984.01-1987.12/E15S 1488 Petrol 55 kW 75 BHP (1984.01 - 1987.12) Until 05/1985,
Nissan/Sunny/B13/N14 | 1.4/1990.10-1995.06/GA14DS 1392 Petrol 60 kW 82 BHP (1990.10 - 1995.06)
Nissan/Sunny/B13/N14 | 1.4/1990.10-1995.05/GA14DE, GA14DS 1392 Petrol 55 kW 75 BHP (1990.10 - 1995.05)
Nissan/Sunny/B13/N14 | 1.4 16V/1990.10-1995.06/GA14DE 1392 Petrol 64 kW 87 BHP (1990.10 - 1995.06)
Nissan/Sunny/B12/N13 | 1.3/1986.07-1991.10/E13S 1269 Petrol 44 kW 60 BHP (1986.07 - 1991.10)
Nissan/Sunny/B12/N13 | 1.4/1988.10-1990.09/GA14DS 1392 Petrol 60 kW 82 BHP (1988.10 - 1990.09)
Nissan/Sunny/B12/N13 | 1.4/1988.10-1991.08/GA14S 1392 Petrol 55 kW 75 BHP (1988.10 - 1991.08)
Nissan/Sunny/B12/N13 | 1.0/1986.07-1990.09/E10S 988 Petrol 37 kW 50 BHP (1986.07 - 1990.09)
Nissan/Sunny/B12/N13 | 1.3/1986.06-1988.10/E13S 1269 Petrol 44 kW 60 BHP (1986.06 - 1988.10)
Nissan/Sunny/B11 | 1.3/1982.08-1990.08/E13 1269 Petrol 44 kW 60 BHP (1982.08 - 1990.08)
Nissan/Sunny/B11 | 1.5/1982.03-1986.10/E15S 1488 Petrol 55 kW 75 BHP (1982.03 - 1986.10)
Nissan/Sunny/B11 | 1.5/1982.03-1986.05/E15 1488 Petrol 51 kW 69 BHP (1982.03 - 1986.05)
Nissan/Sunny/B11 |1.7 D/1982.03-1986.10/CD17 1681 Diesel 40 kW 54 BHP (1982.03 - 1986.10) ,
