Garrett 880547-5028S Supercore G-Series G50-1900

Garrett G50-1900 supercore — a balanced core assembly (centre cartridge with compressor cover and back plate) for building or rebuilding G-Series turbochargers.

The use of this product above max turbocharger speed is at the owner’s risk, and can result in damage and premature failure.

To protect the turbocharger from overspeed when operating, a speed sensor can be installed into the compressor housing to monitor shaft speed.

Specifications

• Frame: G50
• Bearing: ball bearing
• Rotation: standard
• Compressor wheel: 88 mm inducer, 120 mm exducer, 0.88 A/R
• Turbine wheel: 99 mm inducer, 94 mm exducer, 90 trim
• Max shaft speed: 93 krpm
• Power: up to 1900 HP
• Displacement: 2.5-10.0 L

Fits & compatible parts

• Compatible turbochargers: GTX50

Features

• Outline interchangeable with GTX Gen II turbos
• High flow, high efficiency GTX Gen II comp aero
• G-Series turbine wheel aero increases performance compared to GTX50 Gen II
• Flow: up to 23% more
• Spool: up to +12% (estimated by flow, efficiency, and inertia)
• One-piece lightweight aluminum center hsg/backplate
